Performance focused
Featuring a dual-woofer horizontal format with a pair of 5¼” (133mm) woofers, the Imagine XC is designed for optimal performance when paired with other components in your setup. PSB has matched the Imagine XC carefully in timbre with the other Imagine X models for the best versatility when setting up your home theatre system.

Experience rich, detailed sound
Even the most demanding audiophile will appreciate the rich and detailed cinematic sound that flows from this speaker. Thanks to PSB’s expert approach to the design of the Imagine XC, music and movie sound effects have an added layer of authenticity. With the ability to bring out the musical essence of everything you choose to play, the XC is a welcome addition to your system setup.

Simple and attractive
Just like the other models in the Imagine X range, the XC boasts a simplified and attractive black cabinet design, and can easily be incorporated into any room in your home with ease. The minimalist design of this centre channel speaker allows it to blend well into your system setup and it will also look at home next to modern flat profile TVs.

Specifications

Frequency Response

On Axis @ 0° ±3dB	50 - 23,000Hz
On Axis @ 0° ±1 1/2dB	65 - 20,000Hz
Off Axis @ 30° ±1 1/2dB	65 - 10,000Hz
LF Cutoff -10dB	45Hz

Sensitivity

Anechoic Chamber	88dB
Listening Room	90dB

Impedance

Nominal	8 Ohms
Minimum	4 Ohms

Input Power

Recommended	20 - 150 Watts
Program	150 Watts

Acoustic Design

Tweeter (Nominal)	1" (25mm) Titanium Dome with Ferrofluid Neodymium Magnet
Woofer (Nominal)	2 x 5 1/4" (133mm) Injection Moulded Clay/Ceramic reinforced Polypropylene Cone Rubber Surround Dual Magnet
Crossover	1,800Hz, LR4
Internal Volume	0.58 cu ft (16.4L)
Design Type	Bass Reflex Rear Port

Dimensions / Weight / Finish

Size (W x H x D)	19 1/8 x 6 3/4 x 11 1/8" * 485 x 170 x 280mm
Weight	Net - 19.8lb (9kg)/each Sipping - 22.2lb (10.1kg)/each
Finish	Black Ash
Notes	* Non-metric measurements are approximate. All specifications are subject to change without notice.
